Air Entrainment Meter

Air Entrainment Meter

Air Entrainment Meters are used for determining the air content of fresh concrete.
They consist of a flanged 7 or 8 liter capacity cylindrical vessel and cover assembly incorporating a pressure gauge, air pump and valves.
They have a quick action clamping system.
It is not affected by changes in barometric pressure.
Direct pressure gauge reading to the nearest 0.1% up to 6%, 0.2% from 6 to 8 and % 0.5  from 8 to 15.
Calibration vessels and compacting bar with square section should be ordered seperately.

Standards: EN 12350–7 | ASTM C231 | AASHTO T152
The Air Entrainment Meter is supplied complete with :
Straight Edge
An inner and an outer (J-Type) calibration pipes
Tamping Rod, Ø16×600 mm
Special Carrying Case
