Bifilar and Trifilar Apparatus

Bifilar and Trifilar Apparatus

Product Code: CHINAELABC2580003

Categories: Applied Mechanics Lab Equipment

Tags: Bifilar and Trifilar Apparatus

2461

Download PDF Enquire Now
  • Description

Bifilar and Trifilar Apparatus



Specification

The experimental unit is designed to be fixed to a wall.
In a bifilar suspension, the pendulum body is suspended over two threads.
The pendulum body oscillates in a plane purely transnationally without rotation.
This kind of pendulum can be considered as a mathematical pendulum.

In a trifler suspension with three threads, the pendulum body is set in a torsional vibration.
The torsional vibration can be used to determine the moment of inertia by experiment.
A beam, a cylinder or a circular ring are used as pendulum bodies.
The length of the threads can be adjusted using clamping devices.
The moments of inertia of the pendulum body can be calculated from the measured oscillation period.
The oscillation period can be varied by changing the thread length.

Features:
Ideal mathematical pendulum can be demonstrated.
Moment of inertia in an experiment on a rotary pendulum.
