Power Door Lock System Trainer

Power Door Lock System Trainer

Product Code: CHINAELABC2640021

Categories: Automobile Engineering Lab Equipment

Tags: Power Door Lock System Trainer

2970

Download PDF Enquire Now
  • Description

Power Door Lock System Trainer



Specification

FEATURES:
OEM components (door lock actuators, switches, with OEM matching wire colors).
A lockable system fault box allowing instructors to insert from one to four faults for student diagnostic learning.
Electrical test points are included on the trainer for circuit diagnosis.
Students can wire this circuit using supplied leads and included OEM wiring diagrams.
Trainer requires an external 12V DC power supply to operate.
User manual included.

SPECIFICATIONS:
Power door lock actuators (2ea).
Door lock relay.
Fault box with 4 faults.
Test points for diagnosis.
Set of 21-jumper leads, 24” (60cm) (6 red, 1 black, 14 blue).
