TYPE A Air Entrainment Meter Cap 0.005 cum

TYPE A Air Entrainment Meter Cap 0.005 cum

3709

Download PDF Enquire Now
  • Description

Air Entrainment Series - TYPE A Air Entrainment Meter Cap 0.005 cum, Air Entrainment Meter, Cp. 0.007 cum, Air Entrainment Meter, Cap. 0.01 cum, Air Entrainment Meter, Cap. 0.1 cu m



Specification

Suitable for concrete containing 38 mmnominal maximum sized aggregate. The apparatus consists of a measuring bowl of 0.005 cum. capacity. A flanged conical cover assembly fits over the bowl that can be sealed with clamps keeping a rubber gasket in between.

A water inlet valve with a spray tube and air bleed valve are fitted on the conical cover assembly.
A pressure gauge is mounted on the top of the stand pipe. A hand pump is provided for application of pressure. Supplied complete with one calibrating cylinder, a rubber mallet, one measure and one tamping rod.
But the capacity of the bowl is 0.007 cu m. It is used for concrete containing 38 mm maximum sized aggregate.
But the capacity of the bowl is 0.01 cu m, for use with concrete containing 75 mm maximum sized aggregate.
But the capacity of the bowl is 0.1 cu m. Suitable for concrete containing 150 mm maximum sized aggregate.
