Hoek Type Triaxial Cell For Nx size cores

Hoek Type Triaxial Cell For Nx size cores

3646

Download PDF Enquire Now
  • Description

Triaxial Test Equipment - Hoek Type Triaxial Cell For Nx size cores



Specification

Basic Cell of steel body.
Two nos. steel end caps.
Two nos. loading pistons, each incorporating a spherical seating.
Two nos. self sealing couplings, one for connecting to hydraulic pressure system and the other for deairing the cell chamber or attachment of pressure measuring device, if required.
Load spreader pads to prevent damage to the platens of Compression Testing Machine/Loading Unit.
Six Nos. sleeves made from special rubber, capable of withstanding high lateral pressure.
