Ramsbottom Carbon Residue Apparatus

Ramsbottom Carbon Residue Apparatus

Ramsbottom Carbon Residue Apparatus:
Microprocessor temperature control with digital display and over temperature cut-off.
Thermostatically controlled coking furnace for five samples.
Heavily insulated stainless steel cabinet with three-layer refractory top provides excellent heat retention.
Cast-iron block type furnace reaches the standard test temperature of 550°C (1022°F) rapidly and controls with ±1°C stability.
Microprocessor temperature control has °C/°F switchable digital setpoint and display.
Operator and equipment are protected by an over temperature control circuit which automatically interrupts power to the unit should block temperature exceed the programmed cut-off point.
Communications software (RS232, etc.), ramp-to-set and other enhanced features are available as extra cost options.

Ramsbottom Carbon Residue Apparatus Specifications:
Conforms to the specifications of: ASTM D524, D6074; IP 14; ISO 4262; FTM 791-5002; NF T 60-117
Furnace Type: Cast iron block
Capacity: 5 coking bulbs
Controller Sensitivity: ±1°C (± 2°F)
Maximum Temperature: 650°C (1200°F)
Heater: 0-2400W, ceramic band heater
Electrical Requirements : 115V 60Hz, Single Phase, 20.8A;  220-240V 50/60Hz, Single Phase, 10.9A
