Transformer Turns Ratio Tester

Transformer Turns Ratio Tester

Automatic cutoff after test
Saves 30 test results
Meets specs of IEC 60076
Fuse protection for line short circuit
Fuse and reset protection for reverse connection of HV and LV winding

Description: generation, fully automatic, transformer turns ratio tester designed for measuring ratio, ratio error of single and three phase transformers. The entire test is done automatically and quickly.
Operator enters the test parameters and takes over; powers up the voltage, balances the bridge, takes the readings, and displays the results on the LCD screen. Prints test results through its built-in printer.
A key feature of the automatic measure transformer connection group. LV and HV windings are automatically isolated once the measurement is over.
True portability is achieved by the lightweight (only 10 kg), single unit design housing the. The encased in an aluminum alloy cabinet.
